MIL-PRF-81705E

TABLE I. Performance requirements � Continued.

Characteristics

Applicable to

Requirements

Test

types

Paragraph

Reference

Surface resistivity

I, III

Inner: Greater than

4.6.8

or equal to 1x105

ohms/sq but less

than 1x1012

ohms/sq.

Outer: less than

1x1012 ohms/sq

Electrostatic shielding

I, III

4.6.9

Voltage test

30 volts peak

(max)

Energy test

10nJ (max)

Storage stability

4.6.10

1. Seam strength (use as received conditions)

I, III

No separation

2. Surface resistivity

Inner: Greater than

or equal to 1x105

ohms/sq but less

than 1x1012

ohms/sq.

Outer: less than

1x1012 ohms/sq

3. Static decay

I, III

Not greater than 2

seconds

4. Electrostatic shielding

I, III

Voltage test

30 volts peak

(max)

Energy test

10nJ (max)

4. VERIFICATION

4.1 Classification of inspections. The inspection requirements specified herein are

classified as follows:

a. Qualification inspection (see 4.2).

b. Conformance inspection (see 4.3).
